Router for Nauta Hogar TP-Link TD-8961N

SKU: YAS-0000000001430 Categories: , ,
THIS PRODUCT WILL ARRIVE AT OUR ENTITY IN THE MONTH OF DECEMBER, IT COMES PRECONFIGURED FOR SERVICE

NAUTA HOME

IT IS ORIENTED TOWARDS THE POPULATION, MYPIMES, TCP AND CNA, FOR REPLACEMENT OF EQUIPMENT
OF THE NAUTA HOGAR SERVICE.

INTERESTED CUSTOMERS CAN RESERVE THEM (DO NOT EXECUTE THE PAYMENT FOR THE PRODUCT TO
MAKE THEIR RESERVATION EFFECTIVE),  THEY WILL BE CONTACTED AS SOON AS THEY ARE IN OUR
WAREHOUSES AND CAN BE PAID.












CUP: $19,700.00


Available on backorder
































Description





All-in-One Device: ADSL2+ Modem, NAT Router, 4-Port Switch and Wireless N Access Point
Wireless N speed of up to 300Mbps makes it ideal for heavy bandwidth consumption or interruption sensitive applications such as online gaming,
Internet calling and even high definition video streaming
Setup Wizard with multi-language support offers quick and hassle-free installation
Secure Wireless encryption by pressing the WPS button and easy access to Wi-Fi with the on/off button






Interface  4 RJ45 10/100Mbps
Ports 1 RJ11 Port





Button 1 On/Off switch
1 WPS button





External Power Supply 9VDC/0.85A





IEEE Standards IEEE 802.3, 802.3u



ADSL Standards Full-rate ANSI T1.413 Issue 2,ITU-T G.992.1(G.DMT),ITU-T G.992.2(G.Lite)ITU-T G.994.1 (G.hs),ITU-T G .995.1


ADSL2 standardsITU-T G.992.3 (G.dmt.bis),ITU-T G.992.4 (G.lite.bis)





ADSL2+ITU-T G.992.5 standards






Dimensions (W X D X H)7.7 * 5.1 * 1.4 in. (195 * 130 * 35 mm)
Antenna Type Fixed Omnidirectional
Antenna Gain 2x5dBi

WIRELESS FEATURES
Wireless Standards IEEE 802.11n, 802.11g, 802.11b
Frequency 2.400-2.4835GHz
Transmission Power <20dBm(EIRP)Wireless
SecuritySUPPORTS 64/128 bit WEP, WPA-PSK/WPA2-PSK, Wireless MAC Filtering




SOFTWARE FEATURES






Quality of Service Highlighted QoS based on IPP/ToS, DSCP and 802.1p
Advanced Features
Traffic Shaping (ATM QoS) UBR, CBR, VBR-rt, VBR-nrt;
Dynamic Host Configuration Protocol (DHCP),
DHCP Relay;
Address Translation Network (NAT);
PVC / Ethernet Port Mapping / URL Filtering,
Denial of Service (DoS),
SYN Flooding,
Ping of Death Administration Web Based Configuration (HTTP),
Remote Administration,
Telnet Administration,
Command Line Interface, SSL for TR-069, SNMP v1/2c, SNMP over EOC ,
Web-based Firmware Update,CWMP(TR-069),
Diagnostic ToolsPort ForwardingVirtual Server,
DMZ,
ACL(Access Control List)VPN Pass-ThroughPPTP,
L2TP,
IPSec Pass-throughATM/PPP ProtocolsATM Forum UNI3.1/ 4.0,PPP over ATM (RFC 2364),
PPP over Ethernet (RFC2516),
IPoA (RFC1577/2225),PVC - Up to 8 PVCs








Certification CE,
FCC,
RoHSPackage
Contents TD-W8961N
External Splitter RJ-11
Telephone Cable
RJ-45 Ethernet Cable
Quick Installation Guide
Installation CD
Power Adapter
