6 KWh split phase 110/220V kit with Growatt 3000W 48V inverters connected in parallel

SKU: S6KW_2GROW Categories: , , , ,
Photovoltaic kit designed to support installations of up to 6 KW
demand with parallel inverters to achieve split phase at
110/220 V voltage. Designed to charge batteries using photovoltaic
solar energy and/or the electrical grid. This kit allows the connection of 220V
equipment such as air conditioners and split units.
It has the capacity for subsequent growth in demanded power.

CUP: $3,473,338.00

Description

The kit is composed of:

Monocrystalline Solar Panel, monofacial, 144 cells, 550W                           one               12
Structure for six panels 20 degrees MG Solar                                                  one                2
Deep Cycle Battery 12 Volt 250 Ah                                                                     one                4
Photovoltaic Cable PV 12 AWG 2000 V black                                                  mts               60
Photovoltaic Cable PV 12 AWG 2000 V red                                                      mts               60
6 AWG black cable,                                                                                                 mts               10
6 AWG red cable                                                                                                      mts               10
MC4 connector                                                                                                        pair                4
Fuse holder                                                                                                               one                4
Fuse 15A                                                                                                                    one                4
Miniature DC Circuit Breaker 2 Pole 63 Amps 500V DC                               one                2
275A DC12-48V Battery Disconnect Switch                                                      one                2
Renogy set with ANL fuse holder +100A                                                           one                2
4 AWG gauge copper wire, Maximum current 150 A                                      one                10
Tinned Copper Connectors 4 x 5/16, 4 AWG                                                    one                20
OMNIUM IP65 charging center for 6 modules                                                one                 1
CIRCUIT BREAKER 2P 220V 63A CE APPROVED                                        one                2
12 module plastic distribution box                                                                      one                 1
Growatt 3000W 48V Solar inverter charger 120V                                          one                 2

Technical Data Sheet Talesun PV Panels 540W Bifacial Dual Glass

Technical Data Sheet of the Growatt SFP3000TL LVM-24P Inverter Charger

Technical Data Sheet AGM Deep Cycle Battery RN12-250 12V 250AH

Installation service: 94,500.00 CUP

Note: The service does not include transportation, lodging and food costs for staff in case of transfers outside the province.
If any extra material is necessary for installation, it will be agreed with the client on site.
