Description
This kit is composed of:
Monocrystalline Solar Panel, monofacial, 144 cells, 550W one 12
Structure for six panels 20 degrees MG Solar one 2
Deep Cycle Battery 12 Volt 250 Ah one 4
Photovoltaic Cable PV 12 AWG 2000 V black mts 50
Photovoltaic Cable PV 12 AWG 2000 V red mts 50
6 AWG black cable, mts 10
6 AWG red cable mts 10
MC4 connector pair 8
Fuse holder one 4
Fuse 15A one 4
Miniature DC Circuit Breaker 2 Pole 63 Amps 500V DC one 2
Battery Disconnect Switch 275A DC12-48V one 1
ANL-150A fuse one 2
4 AWG gauge copper wire, Maximum current 150 A one 10
Tinned Copper Connectors 4 x 5/16, 4 AWG one 14
CIRCUIT BREAKER 2P 220V 50A CE APPROVED one 2
12 module plastic distribution box one 1
Sun W6000 SP - 6000W-48V Solar Inverter, 120/240V one 1
Sun MS 50A - MPPT Solar Charge Controller 50A one 1
Installation service 94,500.00
Technical Data Sheet Talesun PV Panels 540W Bifacial Dual Glass
SUN 6000W 48V inverter technical sheet
Technical Data Sheet AGM Deep Cycle Battery RN12-250 12V 250AH
Note: The service does not include transportation, lodging and food expenses for staff in case of transfers outside the province.
Nor are the auxiliary materials necessary to adapt the kit to the configuration of the home included: cable, gutters, pipes and
accessories, which will be agreed upon with the client at the time of signing the contract.
